Cured in Place Pipe Lining Services
Orlando Commercial  & Industrial Plumbing

CIPP lining, or cured in place pipe lining, is a method of pipe restoration used in existing pipe repair. This process is done to preserve current pipes that have been damaged by leaks, cracks, intruding roots, and rust. It increases the lifespan of a pipe system while also possibly preserving building structures and causing little to no damage to property.

Commercial Cured In Place Pipe Repair - CIPP

Commercial and Industrial Cured in place pipe lining repair services. The trenchless pipe lining or sewer pipe lining is a preferred method used to rehabilitate damaged pipelines. The CIPP trenchless pipe liner technology is versatile and can be used for various pipeline systems, including cast iron pipes, abs, PVC, HDPE, clay, Orangeburg, metal and/or concrete pipes. Cloud 9 Services, Inc. is a leader in the Orlando, Florida area providing its customers with cured in place pipe repair “CIPP”.

The cured in place pipe liners are made of tubular layers. They are non-woven felt with an exterior polyurethane coat. A CIPP wet out is when the resign mixture is saturated into the felt. The felt then acts as resin carrier adding flexibility to the liner.



Once the wet out is completed, the CIPP is moved to the installation site. When the cured in place pipe liner has arrived, it is positioned into the host pipe. Then, the cured in place pipe liner is fully inflated by water or air pressure. Once completed, the tube cures in place.

Perhaps the strongest aspect that Cloud 9 Services, Inc. brings to its customers is the diversity in pipeline rehabilitation. While Cloud 9 Services, Inc. does focus on cured in place pipe-line repairs, we are committed to a full system renewal. Cloud 9 Services, Inc has the capabilities for cleaning the pipeline, video inspections, slip-lining, lateral rehabilitation, hydro excavation, and more!



Searching for cipp pipe lining companies or more info on pipe lining. Give us a call at (407) 481-2750!

Cured In Place Pipe Lining Process

For more than 10 years, Cloud 9 Services has been a leading company and expert underground utility contractors. Our team specializes in utility construction, repairs, and maintenance. Over the years, we have developed and expanded our services. One of those services is cured in place pipe repair also known as CIPP or trenchless pipe lining and repair.



CIPP is the latest and most popular technology used to repair pipes. This process is used to fix deteriorated pipes using minimal disorder to the environment.



Commercial Cured in place pipe lining is one of the most efficient ways to get the job done. The CIPP restoration process involves a trenchless technology. Cured in place pipe lining does not need excavation in order to rehabilitate a damage or broken pipeline. Many times the liner can be inserted through an existing access point or manhole.



Recently, Cloud 9 Services teamed up with Picote Solutions and Perma Liner for a cured in place pipe repair at the National Aeronautics and Space Administration, also known as NASA.



Our work with NASA consisted of lining a 40 year old pipe that was 8” x 150.

What does the process of CIPP look like?

When our team is on site of a CIPP we inspect the pipe using our video pipe inspection technology. Once we determine the location of the damage, the liner is inverted using water or air pressure.



Next, an epoxy resin felt tube is placed into the damaged pipe from an access point, whether through a manhole or excavation. The liner is then pressurized and shot into the pipe system.  Then, we inspect the pipe system once again to make sure the liner is placed properly. We then place pressure for the resin to harden and form a tight fitting and jointless new pipe.The Picote Coating System is quite simple. It is attached to a coating pipe and the solid epoxy resin cartridges begin to pump. This forms what we call a “pipe inside of a pipe”. The new pipe is much stronger and durable.

How powerful is the coating?

The coating placed inside the pipe system provides a damp-proof, corrosion resistant, wear-resistant and non-corrosive lining. Several coats can be applied to the same pipe. This ensures that the system is fully protected and strengthened. The powerful coating enhances the longevity of the pipe. On average, a cured in place pipe is made to last up to 100 years.

Cast Iron PipeLiner

Cast Iron Pipes that are exposed to waste water will deteriorate over time.



Trenchless pipe repair addresses the problem by inserting a strong epoxy cure into the pipe so that it sticks to the inner walls. This will create a hardened liner, serving as a pipe inside the old cast iron pipe, rehabilitating the old system to save on replacement costs.

Sleeves For A Sewer Pipe

Trenchless sewage system repair work is an approach of repairing sewer pipes that returns the interior framework of an existing pipeline without untidy and disruptive digging. The entry opening of a pipe is the center of all inner repair work. A video pipe inspection of the pipe system is done to identify the actual damages. An epoxy saturated felt sleeve is put into the damaged pipeline. The sleeve is inflated and develops the new piping.



To draw the liner with the wanted place, two access factors are needed: one to feed the lining as well as one to pull it via. Air is presented into the pipe to open the sleeve and also hold it versus the internal walls of the pipeline until it dries in position. After the pipe is cured, a follow-up video assessment is done to confirm the pipe is fixed appropriately.

Cured in Place Pipe-lining Installation

We use a 3 step process at Cloud 9 Services, Inc

  • First- We inspect the pipe-lines with a self- working, HD sewer video camera. This allows us to not only measure the pipe but also see the extent of the damage. After the inspection is completed, we create an action plan to repair all pipe problems

  • Second- Once we properly assess the damage and propose a solution we thoroughly clean the lines using our high-pressure water jetter and special tools to remove FOG (fat, oil, grease); dirt & mud; tree roots; debris; etc.

  • Third- After the pipe is cleaned we line the pipe. We pull a new CIPP liner in place and saturate it with an epoxy cure. The liner will then inflate causing the pipe to cure in place. The end result is the creation of a strong, smooth and seamless ‘pipe within a pipe.

Benefits of Cured in Place Pipe-lining

The repaired pipe is better and stronger:

 Roots cannot penetrate the new “jointless” pipe and calcification won't stick to the inner walls of the epoxy barrier-lined pipe.

Cured in Place Pipe FAQ

Can a CIPP pipe liner be installed on a vertical pipe or only horizontal?

Our CIPP pipe lining system can be installed on both vertical and horizontal pipes. “CIPP” Pipe liner can even be installed inside asbestos covered pipes or inside architectural stone pipes. Our crews here at Cloud 9 Services, Inc. have performed 100s of trenchless sewer pipe relining projects.

What is trenchless pipe repair?

Trenchless pipe repair is a preferred method to traditional sewer pipe repair. It is a 'zero dig' process used to restore sewer pipes.

What is the cured in place pipe lining cost per foot?

The cost of cured in place pipe lining installation varies on an individual basis. Some determining factors are; pipe size, how much cleaning the pipe needs, and the difficulty to access the pipe. Regardless, cured in place pipe repair is more affordable than traditional sewer line repair.

How long does pipe lining last?

Our trenchless pipe repair technicians are experts at creating pipes that are built to stand the test of time. The epoxy resin coating applied to the pipe system provides a damp-proof, corrosion resistant, wear-resistant and non corrosive lining. This lining ensures that the system is completely protected and strengthened to last for decades. On average, a trenchless pipe can last up to 100 years. With average use, the new cured in place pipe will be protected against any root intrusion, cracks, leaks and other damages associated with underground utilities. Reach out to one of our expert technicians for your pipe lining concerns. Someone is always ready and willing to help you.

How much does trenchless pipe lining cost?

As previously mentioned trenchless pipe relining is the preferred method used to rehabilitate and restore damaged pipes. It is so popular because it requires zero excavation. As all underground utility projects, this repair service varies by size and location.

We always recommend you have an inspection first before an estimate. When one of our trenchless pipe repair technicians perform an inspection, you are able to get an accurate explanation of what is wrong with your pipe. However, we can assure you that it will be more cost effective then having a traditional pipe repair method done. The job is completed without having to excavate the property, meaning it will save the property owner time and money.

How much does epoxy pipe lining cost?

Hiring a contractor to fix a small length of damaged pipe costs around $45 - $200 per hour plus a nominal charge for the material. The epoxy can line a pipe with minor cracks for an immediate repair of a small crack. Larger cracks often require replacement. However, the costs at the end of the day are priced upon individual needs so you should reach out to one of our expert contractors for an estimate.

Does Sewer Pipe Relining Work?

Fixing damaged pipes the traditional way can turn into a costly and time consuming project. However, sewer pipe relining has become the preferred method because. This method is so effective because you do not have to replace your sewer lines or completely destroy the area around them. Once the repair is completed, the new ‘pipe inside the pipe’ has the ability to last up to 100 years.

Hire a Professional Pipe-lining Company Today!

With cured in place pipe repair, your project gets done quickly, with precision and reduces damage and disruption to the surrounding areas.

If you have any further questions about cured in place pipe lining, give us a call at Cloud 9 Services Inc.



We are equipped to handle all underground sewer pipe repair services.



To get a quote, click on the drop-down box below.
